Vacuum Pumps

Our deep experience in producing Vacuum Pumps guarantees reliable vacuum technology.

A reliable and consistent vacuum supply is a basic and fundamental aspect in any milking system. We have over 30 years' experience producing vacuum systems, which means that we can offer a truly comprehensive range of Vacuum Pumps for any type of milking system or herd size: flanged and dry vacuum units, for milking trolleys and buckets, belt-driven/direct-driven and oil-lubricated vane vacuum units for mid- and large-size herds, and lobe pumps for the most advanced requirements. We offer vacuum units complete with base plate, three-way capillary oiler, silencer and non-return valve, compatible with our VARIOSPEED VCU drive. The compact design ensures easy installation and minimal maintenance.

milk pumping machine Main Features
  • Different kind of vacuum pumps according to the Dimension of the system.
  • Pneuma pulsator.
  • 30 Lt hard plastic stainless-steel milk bucket.
  • Compact design.
  • Easy installation.
  • Wide range of different configurations and accessories.
  • Can be controlled by our VARIOSPEED VCU drive.
milking vacuum pump for sale
  • EFFICIENT AND RELIABLE VACUUM SUPPLY
  • DURABLE
  • LOW MAINTENANCE
HPU VACUUM UNITS

Our HPU vane vacuum units have v-belt transmission and squared pumps to optimise heat dispersion. The three-way capillary oiler ensures precise oil dosing and no waste.

Technical Specifications
Product category/Pump type Belt-driven and oil-lubricated vane vacuum pump
Airflow capacity [lt/min at 50 kPa] From 330 to 3,000 l/min
Rpm From 970 to 1,500
Motor power [kW] From 0.75 to 7.5
Available configurations On plate, with or without vacuum tank
Optionals Hot-dip galvanised vacuum tank – from 22 to100 l,Cyclone oil recirculation system, Gear reduction unit, Our VARIOSPEED VCU
vacuum pump for milking machine
SILENT

Our SILENT vane vacuum units, thanks to direct-drive technology, ensure lower noise operation and guarantee higher performance with less energy consumption.

Technical Specifications
Product category/Pump type Direct-driven and oil-lubricated vane vacuum pumps
Airflow capacity [lt/min at 50 kPa] From 430 to 2,100 l/min
Rpm From 1,370 to 1,400
Motor power [kW] From 1.1 to 5.5
Available configurations On plate, with or without vacuum tank
Optionals Hot-dip galvanised vacuum tank – from 50 to100 l VARIOSPEED VCU
vacuum pump for cow milking machine
LPU VACUUM UNITS

Our LPU vacuum units are extremely high-performance and reliable solutions for advanced milking systems. Thanks to lobe technology, no oil is needed, and minimum maintenance is required.

Technical Specifications
Product category/Pump type Lobe vacuum pumps
Airflow capacity [lt/min at 50 kPa] From 2.100 to 4.300 l/min
Rpm 3,600
Motor power [kW] From 5,5 to 11
Optionals Automatic belt tensioner, Cabinet, VARIOSPEED VCU, LOBE CLEANER & the lobe pump automatic cleaning system
